ocTOPus Ultra
ocTOPus® Ultra mooring ropes are made from the best grade Ultra High Molecular Weight Polyethylene. It offers the highest tensile strength to weight ratio. ocTOPus® Ultra is approximately one tenth of the weight of steel wire rope of the same diameter and handling of a rope with breaking strength of several hundred tons is no obstacle for one person.
Construction:
- 12-strand braided rope with Polyurethane coating
- Standard Length 220 mtr (can be customized)
Benefits:
- Specific Gravity : 0,97 , floating
- Melting Point : 150 C
- Elongation 4 %
- Fully UV stabilized
- Wet strength equals dry strength
- Does not absorb water
- Excellent chemical resistance
- Produced in accordance with OCIMF MEG4 guidelines and IACS approved
Specification:
| Dia (mm) |
Cir (inch) |
Line Design Break Force, LDBF (ton) |
Weight (KGs/220m) |
| 22 | 2-3/4 | 50,0 | 68,5 |
| 24 | 3 | 58,0 | 80,5 |
| 26 | 3-1/4 | 66,0 | 92,1 |
| 28 | 3-1/2 | 74,0 | 104,6 |
| 30 | 3-3/4 | 81,5 | 117,0 |
| 32 | 4 | 88,5 | 128,2 |
| 36 | 4-1/2 | 104,0 | 153,0 |
| 40 | 5 | 127,0 | 189,0 |
